[vc_row][vc_column][vc_column_text]When your major considerations include energy efficiency, noise buffering and beauty, a Haas Insulated Steel 600 Series commercial door will exceed your expectations. These doors feature CFC-free polyurethane foam injected between the door panel skins to provide strength and durability. A unique, multi-component paint system and sturdy hardware provide years of dependable performance. [/vc_column_text][/vc_column][/vc_row][vc_row][vc_column width="1/2"][vc_column_text] 1-3/8”-Thick CFC-Free Polyurethane 13.45 Calculated R-Value 26-Gauge Galvanized Steel Full Thermal Break Available with Wind Load 21 Color Options 10-Year Rust & Delamination Warranty 1-Year Hardware 1-Year Spring [/vc_column_text][/vc_column][vc_column width="1/2"][vc_column_text] 2” or 3” track Double steel end stiles Exhaust port Cam safety device Spring bumpers Chain hoist High cycle springs High cycle rollers Wind load rating Glazing (windows) Keyed lock [/vc_column_text][/vc_column][/vc_row]

ENERGY EFFICIENCY The HAAS 700 Series garage doors are 1-3/4″ thick. The R-Value for this product is 16.18. Rigid vinyl extrusions with positive thermal breaks are used to eliminate metal-to-metal contact, which limits the transfer of temperature. Tongue-and-groove construction and section joint seals at meeting rails provide optimum water and wind resistance. A full-length, one-piece vinyl astragal retainer and flexible vinyl U-shaped weatherstrip prevents infiltration of air, rain, snow, and debris. The seal fits to irregular or unlevel floors and reduces impact shocks when the door is closed against concrete flooring. EXCEPTIONAL STRENGTH All Haas doors are built strong. The high-density CFC-free polyurethane foam expands and adheres to the interior and exterior steel panels to provide a rigid unitized structure. Our doors are reinforced with roll-formed galvanized steel struts and double-end hinges, as required to meet all local windload specifications. 1. Section Joint Seal 2. Thermal Break 3. Tongue-and-Groove Construction 4. Polyurethane Insulation 5. Nominal 18-Gauge Interior Plate for Hinge Attachment 6. U-Shaped Astragal UNIQUE PAINT SYSTEM Haas Door’s paint thickness is one of the highest in the industry. Our three-tier, corrosion-resistant protective paint system is designed to resist even the most hostile weather conditions. Most of the 600 SERIES models are available in 10 colors. The protective layers found on both the interior and exterior are: 1. Injected Polyurethane Foam 2. Steel 3. Galvanizing 4. Epoxy Primer 5. Polyester Finish Coat HARD WORKING HARDWARE The track is 2 or 3″ galvanized steel, depending on door size, with bracket mount for wood jambs or continuous reverse mounting for steel jambs. For angle-mount track, door widths are 2″ wider than opening. Track rollers are 2 or 3″ case-hardened inner and outer steel races with 10-ball, prelubricated bearings. Hinges, brackets, and reinforced struts are hot-dipped galvanized steel, and fasteners are plated for maximum corrosion resistance. Counterbalancing springs are torsion type, computer calibrated to match door load. This provides a 10,000 cycle life at the minimum; optional spring wires can achieve 25,000, 50,000, and 100,000 cycle requirements. Springs are wound from oil-tempered wire and mounted on a continuous cross header tube or solid shaft, as determined by torque load.

HAAS 2000 Series garage doors stand up to the elements — insulating, dampening noise,and enhancing your building’s aesthetics at the same time. These insulated steel doors help increase energy savings with the polyurethane-foam cores. Our doors are reinforced with roll-formed galvanized steel struts and double-end hinges, as required to meet windload specifications and to comply with ANSI A216.1 and NAGDM 102-1988. Our three-tier, corrosion-resistant protective paint system is designed to resist even the most hostile weather conditions. Haas Door’s paint thickness is one of the highest in the industry. Most of the 2000 SERIES models are available in 10 colors. HARD WORKING HARDWARE The track is 2″ or 3″ galvanized steel, depending on door size, with bracket mount for wood jambs or continuous reverse mounting for steel jambs. For angle-mount track, door widths are 2″ wider than opening. Track rollers are 2″ or 3″ case-hardened inner and outer steel races with 10-ball pre-lubricated bearings. Hinges, brackets, and reinforced struts are hot-dipped galvanized steel. Fasteners are plated for maximum corrosion resistance. Counterbalancing springs are torsion type, computer calibrated to match door load. This provides a 10,000-cycle life at the minimum; optional spring wires can achieve 25,000, 50,000 and 100,000 cycle requirements. Springs are wound from oil-tempered wire and mounted on a continuous cross header tube or solid shaft, as determined by torque load. You can contact or one of our professional dealers for information on additional options, including: exterior cylinder locks, chain hoist operation, safety bottom brackets, and special lift clearance tracks (high lift, vertical lift, low headroom, and those that follow the roof line). Optional Aluminum Full View sections provide maximum light and visibility with available insulated glazing. Pass through doors are also available on the 2000 SERIES. ENERGY EFFICIENCY 2000 SERIES doors are 2″ thick. The calculated R-Value for this product is 17.66. Rigid vinyl extrusions with positive thermal breaks are used to eliminate metal-tometal contact, which limits the transfer of temperature. Tongue-and-groove construction and section joint seals at meeting rails provide optimum water and wind resistance. A full-length, one-piece vinyl astragal retainer and flexible vinyl U-shaped weather-strip prevent infiltration of air, rain, snow and debris. The seal reduces impact shocks when the door is closed against concrete flooring.

The outstanding features and benefits of the Haas Door 800 Series have made them the door of choice among commercial and industrial architects. The 800 series insulated sectional steel doors feature a full 3″ pressure-injected core of high-density CFC-free polyurethane foam insulation, with an R-Value of 25.8 – the highest in the commercial door industry. Therma-Pro™ is exceptionally strong. All Therma-Pro™ doors are reinforced with roll-formed galvanized steel struts and double-end hinges as required to meet or exceed local wind load specifications. Haas Door’s Therma-Pro™ is the ideal door for applications that require both maximum energy efficiency and strength FEATURES 1 Maximum Energy Efficiency A 3″ pressure-injected core of high-density CFC-free polyurethane foam insulation is bonded to the inner surfaces of the exterior and interior face sheets or panels. To ensure maximum energy efficiency and strength, the foam is pressure-injected into each section of the door at approximately 2.5 pounds per cubic foot and is carefully cured in a temperature-controlled environment 2 All-Steel Construction Face sheets are heavy-duty, roll-formed, galvanized steel. Model CHT-816 features a 26-gauge, wood-grain texture with horizontal V-grooves every 3″ on both the exterior and interior face sheets. Model CHT-832 has a 20-gauge flush-smooth surface on the exterior face sheet and a 26-gauge wood-grain texture with V-grooves on the interior. 3 Tongue & Groove Section Joints Tight sealing tongue-and-groove section joints add wind resistance and strength, prevent air and water infiltration, and provide a full 1-3/4” thermal break to prevent temperature transmission. 4 Bottom Weatherseal Full-length vinyl astragal retainer and flexible U-shaped bottom weatherseal provide a tight seal at the floor to resist rain and snow and absorb the shock of repeated closing. 5 Steel End Stiles End stiles are formed from 16-gauge galvanized steel and feature vinyl end caps to create a thermal break 6 Smooth Operation Full-floating ten ball bearing rollers in case-hardened steel races, mounted to fit the slope of the track, assure smooth, easy, and reliable operation. 7 Intermediate Reinforcing Full-length 16-gauge steel back-up plates, inserted prior to foaming, ensure solid attachment of all hardware; also, pre-drilling assures proper positioning. 8 Heavy-Duty Hinges 14-gauge, hot-dipped galvanized steel hinges provide added strength, durability, and reliable performance. JOINT SEAL Tongue-and-groove construction With full-length vinyl top and bottom caps eliminate metal-to-metal Contact and provide energy efficient thermal breaks that limit transfer of heat and cold – a major advantage where conditioned air or controlled temperatures are important. BOTTOM SEAL A full-length, one-piece vinyl U-shaped weather strip seals to irregular or unlevel floors, prevents infiltration of air, rain, or snow, and reduces impact shock when the door is closed against concrete flooring. HEADER SEAL Flexible flap seals the top of the door against the header to seal out air filtration. Seal extends a full 2″ past the front of the door for maximum efficiency. PROTECTIVE FINISH Interior and exterior steel is rust-proofed with hot-dipped galvanizing and pre-painted inside and out with an epoxy primer and an enamel top coat of white, brown, almond, sandstone, hunter green, grey, and bronze. (The interior side is available in white only.) WINDOW OPTIONS Attractive and practical, the 25″ X 12″ insulated 1/2″ tempered glass window inserts provide superior double-glazed insulation. Seal-tight frames and a new anti-condensation system ensure effective sealing and a bright, clear view. Windows are attached from the inside for easy installation and maximum security.
